40W BOX SPEAKER WITH WALL MOUNT
NVS-10500020WS
The NVS-10540040WS is a wall mount speaker with built-in 70V/100V transformer, which makes longer distance transmission and parallel connection of multiple loudspeakers possible. It has strong fire resistant ABS body & metal grill which will ensure long term durability. It comes with metal wall mount brackets for easy installation. It is ideal choice for conference rooms, BGM, etc.
Product Overview
The NVS-10540040WS is a wall mount speaker with built-in 70V/100V transformer, which makes longer distance transmission and parallel connection of multiple loudspeakers possible. It has strong fire resistant ABS body & metal grill which will ensure long term durability. It comes with metal wall mount brackets for easy installation. It is ideal choice for conference rooms, BGM, etc.
FEATURES
- Fire-resistant ABS
- Metal grill
- Separate LF & HF drivers
- Wall-mount bracket
| SPECIFICATIONS | ||
Model | NVS-10540040WS | |
| Rated Power | 40W | |
| Driver Unit | 6.5″×1, 1″×1 | |
| Frequency Response | 65Hz-20KHz | |
| Power Taping Options | 2.5/5/10/20/40W | |
| Input Voltage/ Impedance | 70V/100V/8Ω | |
| Sensitivity (1m,1w) | 93dB±2dB | |
| Maximum SPL (1m) | 109dB±2dB | |
| Coverage angle(HxV) | 120°×80° | |
| Input Connector | Two-wire cable | |
| Operating temperature | -25℃~+55℃ | |
| Material | ABS Plastic | |
| Weight | 4.6 kg | |
| Dimension (H×W×D) | 310×215×203mm | |
| Part Number | Description | Standard Quantity | ||
| NVS-10540040WS | 40W BOX SPEAKER WITH WALL MOUNT BRACKET (BLACK) | 01 | ||
ACCESSORIES INFORMATION
| Description | Standard Quantity |
| User Manual | 01 |
| U-Shape bracket | 01 |
